- Engine Power80V Lithium
- Operating Weight6700kg
- Load Capacity5000kg
Contact your nearest branch for the latest offer. Prices subject to change & T's and C's apply.
Talk to an MCM equipment specialist about specs, attachments, finance & nationwide delivery.
Includes 3-stage 4.5m mast.
The MCM E40 Electric Forklift is a 4-tonne class lithium-powered counterbalance forklift built for heavy industrial work — warehousing, port handling, manufacturing, and any operation that demands strong daily lift performance without diesel noise, exhaust, or fuel cost. Driven by a 76.8 V / 350 Ah lithium battery delivering 6–8 operating hours per charge, paired with a 16.6 kW AC traction motor and a 13 kW lift motor on AC/ZAPI control, the E40 lifts up to 4 000 kg at a 500 mm load centre, travels at 20 km/h loaded or unloaded, and clears full lift in seconds. A 3-stage 4.5 m mast is included as standard.
| Model | CPD40D |
| Rated Load Capacity | 4 000 kg |
| Load Centre | 500 mm |
| Lifting Height | 3 000 mm |
| Free Lifting Height | 135 mm |
| Fork Size (L × W × T) | 1 220 × 125 × 50 mm |
| Mast Tilting Angle (F/R) | 6° / 12° |
| Length (without fork) | 2 915 mm |
| Overall Width | 1 225 mm |
| Mast Height After Mast Fall | 2 180 mm |
| Lift Height | 4 100 mm |
| Overhead Guard Height | 2 070 mm |
| Turning Radius | 2 615 mm |
| Front Overhang | 485 / 570 mm |
| Min. Right-Angle Channel Width | 2 600 mm |
| Wheelbase | 1 860 mm |
| Track — Front | 1 000 mm |
| Track — Rear | 970 mm |
| Ground Clearance — Mast | 130 mm |
| Ground Clearance — Car Centre | 200 mm |
| Travel Speed (Full Load / No Load) | 20 / 20 km/h |
| Lifting Speed (Full Load / No Load) | 380 / 420 mm/s |
| Lowering Speed (Full Load / No Load) | 420 / 460 mm/s |
| Max. Drawbar Pull (Full / No Load) | 2 000 / 1 330 kg |
| Max. Gradeability (Full / No Load) | 16% / 20% |
| Front Tyre | 250–15 |
| Rear Tyre | 650–10 |
| Total Weight | 4 950 kg |
| Battery | 76.8 V / 350 Ah Lithium |
| Traction Motor (S2 60-min) | 16.6 kW |
| Controller | AC / ZAPI |
| Pump | AC / ZAPI |
| Lifting Motor (S3 15%) | 13 kW |
| Work Pressure | 17.5 MPa |
| Operating Hours per Charge | 6–8 h |
Available from MCM Group South Africa with nationwide delivery, finance options, and full after-sales support across our branch network in Midrand, Cape Town, Bloemfontein, and George. Contact us today for current stock, a quote, or a demo.
The MCM E40 Electric Forklift starts from R 434 775 excl. VAT at MCM Group. The final price depends on configuration and any attachments — contact your nearest branch or request a quote for current pricing and available specials.
Yes. MCM Group submits your finance application to multiple banks and asset-finance houses simultaneously — including Nedbank, WesBank and Standard Bank. Approval typically takes 48 to 72 hours and we handle the paperwork end-to-end.
Key specs for the MCM E40 Electric Forklift include Engine Power: Lithium, Operating Weight: TBC, Load Capacity: 4000kg. See the full spec sheet on this page or request the brochure for complete details.
The MCM E40 Electric Forklift is a electric forklift used for indoor lifting and material handling where low emissions and quiet operation matter, such as warehouses and cold stores. It is built for South African conditions and backed by local parts and service support.
The MCM E40 Electric Forklift includes a local warranty, with genuine parts and technical support available through MCM Group's National Parts Division and four branches (Cape Town, George, Bloemfontein, Midrand). Service and warranty are handled in-country — no waiting on overseas suppliers.
Yes. MCM Group delivers the MCM E40 Electric Forklift to all nine South African provinces from our four branches (Cape Town, George, Bloemfontein, Midrand). Same-day collection is available at branches, with transport delivery elsewhere.
Buy the MCM E40 Electric Forklift from MCM Group at any of our four branches — Cape Town, George, Bloemfontein, Midrand — or order online for nationwide delivery, starting from R 434 775 excl. VAT. Phone +27 81 885 0535 or email sales@mcmco.co.za.
